AMTE-300 Adjustable Tilt Electric Assembly Table
ICR247
ICR247SKU: GN-AMTE-300
AMTE-300 Adjustable Tilt Electric Assembly Table
Electronically controlled assembly table for control panel manufacturing, drilling, thread cutting, tapping, channel/rail fitting, component mounting, and wiring. Features variable positioning through linear actuator system to reduce repetitive strain injuries. Supports panels up to 80.5" × 78", load capacity 881 lbs (400 kg). Dual power options: battery OR AC powered. Made in USA.
$4,025
Specifications
| load capacity lbs | 881 |
| load capacity kg | 400 |
| safety rating | 1.25x |
| max panel width in | 80.5 |
| max panel height in | 78 |
| overall dimensions | 68" W × 66" H × 48" D |
| working height in | 33.5 |
| product weight lbs | 380 |
| tilt angle range | 0° - 70° |
| control system | Electronically controlled linear actuator |
| power primary | 120 VAC 60Hz |
| power alternate | 230 VAC 50Hz |
| power battery | Rechargeable battery-operated (optional) |
